TNV5U220S01,03025JJU,Huawei OptiX OSN 9800 Universal Line Board

Huawei OptiX OSN 9800 Universal Line Board TNV5U220S01 03025JJU Overview

TNV5U220S01: 20 x 10 Gbit/s Universal Line Service Processing Board(SFP+,OTN & SDH & Packet)

The U220 board is a universal line board and supports a mix of OTN, SDH and packet services. It can also receive and transmit only one of the three services. The board processes and converts the received service signals into twenty OTU2/OTU2e signals, which are carried over twenty ITU-T G.694.1-compliant DWDM wavelengths.

The U220 board consists of a fabric interface circuit, traffic manager, packet processor, ODUk cross-connect module, OTN processing module, VC cross-connect module, SDH processing module, WDM-side optical module, control and communication module, and power supply module.

In addition to logical ports on the U220 board, this topic describes how the physical ports on the board are displayed on the NMS.

This section lists the U220 board parameters that can be set or queried by using the NMS.

Functions and Features of the TNV5U220S01 Board

Function and Feature	Description
Backplane capacity	The total backplane bandwidth is 200 Gbit/s.
WDM specification	Supports the DWDM specifications.
Tunable wavelength	Supports tunable wavelength optical modules that provide for 40 wavelengths tunable in the C band with 100 GHz channel spacing. Supports tunable wavelength optical modules that provide for 80 wavelengths tunable in the C band with 50 GHz channel spacing.
FEC coding	FEC, AFEC-2 NOTE: Only ports IN1/OUT1 to IN10/OUT10 of the U220 board support AFEC-2 encoding.
Line modulation format	NRZ
OTN overhead protocol	Supports the OTN frame format and overhead processing defined by ITU-T G.709.
OTN overhead	WDM-side OTU2 layer: supports SM overhead processing. ODUk (k=0, 1, 2, flex) layer: supports PM and TCM overhead processing. ODUk (k=0, 1, 2, flex) layer: supports non-intrusive monitoring of PM and TCM overheads.
Intra-board 1+1 protection	Supported NOTE: Supports intra-board 1+1 protection when working with optical protection boards.
ODUk SNCP	Supported NOTE: ODUk SNCP protection is not supported when packet services are cross-connected from the backplane.
Tributary SNCP	Supported
Electrical-layer ASON	Supported
Optical-layer ASON	Supported
Physical clock	Supported NOTE: When the ODU cross-connect granularity of an OTN line port is set to the maximum granularity supported by the port, physical clock synchronization is not supported. The physical clock can be used only after lower-order ODU cross-connections are configured. Parameter Frame Format of Clock Message can be set to HDLC.
IEEE 1588v2	Supported NOTE: Parameter Frame Format of Clock Message can be set to HDLC. A maximum of four channels of IEEE 1588v2 clock signals are supported concurrently. On the V5U220 board, only ports IN1/OUT1 to IN15/OUT15 support IEEE 1588v2.
ITU-T G.8275.1	Supported NOTE: Parameter Frame Format of Clock Message can be set to HDLC. A maximum of four channels of G.8275.1 clock signals are supported concurrently. On the V5U220 board, only ports IN1/OUT1 to IN15/OUT15 support G.8275.1.
ITU-T G.8273.2	Supported NOTE: The board does not support ITU-T G.8273.2 when the system control board is U2CTU.
Outband DCN	Supports communication over ESCs.
Test frame	Not supported
PRBS	Supports the PRBS function on the WDM side.
Latency measurement	Supported
Channel loopback	ODUk (k=0, 1, flex) channel loopbacks
Port loopback	Supports WDM Side Loopback
Alarm and performance event monitoring	Supports the monitoring of BIP8 bytes (Bursty mode) to help locate line faults. Supports the monitoring of the laser bias current. Supports the laser temperature monitoring. Supports the optical power monitoring. Supports the monitoring of OTN alarms and performance events.
