TNU5NP400,Huawei OptiX OSN 9800 Turbo WDM Board

Huawei OptiX OSN 9800 Turbo WDM Board TNU5NP400 Overview

TNU5NP400: 1 x 200G Turbo WDM Line Service Processing Base Board, extend to 400G

The available functional version of the NP400/NP400E board is TNU5.

NP400 and NP400E are PID boards. The NP400 board can be independently used in a 200G system or work with the NP400E board in a 400G system. The NP400E board must work with the NP400 board in a 400G system.

The NP400/NP400E board supports hybrid transmission of OTN, packet services and SDH services. It supports Layer 2 switching, MPLS-TP, and OTN interfaces.

The NP400 and NP400E boards consist of the following similar modules: signal processing module, Turbo WDM optical module, control and communication module, 1588 module, packet processor, SDH processing module and power module. The difference is that the NP400 board has an OADM optical module.

Functions and features of the TNU5NP400 board

Function and Feature

Description

Basic function

NP400/NP400E:

160 x ODU0/160 x ODUflex/80 x ODU1/20 x ODU2/20 x ODU2e/4 x ODU3/2 x ODU4 <-> 1 x OTUC2
Supports hybrid transmission of ODU0, ODU1, ODUflex, ODU2, ODU2e, ODU3, and ODU4 signals.

NP400:

Multiplexes and demultiplexes two optical signals. That is, the NP400 board receives one OTUC2 optical signal from the NP400E board and converts its own OTUC2 optical signal and the OTUC2 optical signal received from the NP400E board into one multiplexed optical signal.
