TMK1UNQ2,03033REW,Huawei Optix OSN 1800 Universal Line Board

Huawei Optix OSN 1800 Universal Line Board TMK1UNQ2 03033REW Overview

TMK1UNQ2: 4 x 10G universal line service processing Board

The UNQ2 board is a universal line board and supports hybrid transmission of OTN (ODU0/ODU1/ODU2/ODU2e/ODUflex/OSUflex), SDH (VC-12/VC-3/VC4), and packet services with the total bandwidth not exceed 40 Gbit/s (the total bandwidth of SDH services does not exceed 20 Gbit/s). It can also receive and transmit one or two of the preceding three service types. The UNQ2 board processes and converts the received service signals into four OTU2/OTU2e signals, which are carried over four ITU-T G.694.1-compliant DWDM wavelengths.

The UNQ2 board consists of switching interface module, signal processing module, WDM-side optical module, control and communication module, and power supply module.

Functions and features of the TMK1UNQ2 board

Function and Feature

Description

Basic function

Provides four line ports to convert a maximum of 32 channels of ODU0, 16 channels of ODU1, 4 channels of ODU2(e), 32 channels of ODUflex, 1000 channels of OSUflex signals to 4 channel of OTU2(e).

For details about the service mapping path, see Application.
