ME0D0EFXFB71 Is Huawei ME60 BSUI-242A Fixed Board
Huawei ME60 BSUI-242 Board ME0D0EFXFB71 03059193 Overview
ME0D0EFXFB71 (24-Port 10GBase LAN/WAN-SFP+ Broadband Service Unit Integrated (BSUI-242A))
ME0D0EFXFB71 Supports 240G line-rate forwarding.
Basic information about the ME0D0EFXFB71
Item |
Details |
Description |
24-Port 10GBase LAN/WAN-SFP+ Broadband Service Unit Integrated (BSUI-242A) |
Part Number |
03059193 |
Model |
ME0D0EFXFB71 |
Card type |
Fixed Board |
Silkscreen |
BSUI-242A 24x10GBase LAN/WAN-SFP+ |
Functions and features of the ME0D0EFXFB71
Functions and Features |
Description |
Basic function |
Supports 240G line-rate forwarding. |
Reliability and availability |
Hot swappable. |
Restrictions and remarks |
1. All 10GE WAN interfaces support the master clock, but do not support the 10GE WAN slave clock. 2. Every four ports form a group. There are six groups in total: 0-3, 4-7, 8-11, 12-15, 16-19, 20-23. Ports can be switched between the 10GE LAN and 10GE WAN modes by port group. That is, mixed use of 10GE LAN and 10GE WAN modes for the four ports in the same interface group is not allowed. 3. This board does not support 10G DWDM optical modules (BOM number: 02314MED). |
