CR5D0LFXFM70,03033HSS,Huawei NE40E P483 24 Port LAN/WAN-SFP+ MACsec Flexible Card

Huawei NE40E P483 24 Port LAN/WAN-SFP+ MACsec Flexible Card CR5D0LFXFM70 03033HSS Overview

CR5D0LFXFM70 (03033HSS: 24-Port 10GBase LAN/WAN-SFP+ MACsec Flexible Card(P483))

The CR5D0LFXFM70 Provides twenty-four GE/10GE ports for auto-sensing line-rate forwarding.

Basic information about the CR5D0LFXFM70

Item	Details
Description	24-Port 10GBase LAN/WAN-SFP+ MACsec Flexible Card(P483)
Part Number	03033HSS
Model	CR5D0LFXFM70
Card type	Flexible Board
Silkscreen	P483-24x10GBase LAN/WAN-SFP+

Functions and features of the CR5D0LFXFM70

Functions and Features	Description
Basic function	Provides twenty-four GE/10GE ports for auto-sensing line-rate forwarding.
Reliability and availability	Hot swappable.
Restrictions and remarks	1. Each port group contains four interfaces: 0-3, 4-7, 8-11, 12-15, 16-19, or 20-23. These interfaces can work in 10GE/GE mode. A port group works in 10GE mode by default and can be automatically switched to 10GE or GE mode. These interfaces can switch between 10GE LAN and 10GE WAN by group. Mixed use of 10GE LAN and 10GE WAN in one group is not allowed. 10G WAN supports only the master clock mode. 2. When the board works with the 02311GSA and 02314MED optical modules, the long-term operating temperature of the optical module ranges from 0°C to 45°C (32°F to 113°F). 3. When an electrical module is used, the network cable of the electrical module conflicts with the ejector lever of the subcard. It is recommended that the electrical module be used only on even-numbered interfaces (such as 0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20 and 22).
Breakout supported	No
Interface rate auto-sensing supported	Supports GE/10GE auto-sensing.
FlexE supported	No
