CR5D00LRXF62,03059901,Huawei Router NE5000E LPUI-1T6 Integrated Line Process Unit CR5D00LRXF62 03059901

Huawei Router NE5000E LPUI-1T6 Integrated Line Process Unit CR5D00LRXF62 03059901 Overview

CR5D00LRXF62 (72-Port 10GBase LAN/WAN-SFP+ Integrated Line Process Unit CM(NE5000E LPUI-1T6-CM))

Item	Details
Description	72-Port 10GBase LAN/WAN-SFP+ Integrated Line Process Unit CM(NE5000E LPUI-1T6-CM)
Part Number	03059901
Model	CR5D00LRXF62
Card type	Fixed Board
Silkscreen	NE5000E LPUI-1T6-CM 72xGE/10GE

Functions and Features	Description
Basic function	Provides seventy-two 10G interfaces for line-rate forwarding.
Reliability and availability	Hot swappable
Restrictions and remarks	Exception {0/8}, {0/9}, {0/22}, {0/23}, {1/8}, {1/9}, {1/22}, {1/23} port, Each 4 physical interfaces is one Group in the order of number. There can be up two modes one time in each Group, such as GE/FE and WAN, GE/FE and LAN, WAN and LAN. These Groups as: {{0/0,0/1,0/2,0/3},{0/4,0/5,0/6,0/7},{0/10,0/11,0/12,0/13},{0/14,0/15,0/16,0/17},{0/18,0/19,0/20,0/21},{0/24,0/25,0/26,0/27},{0/28,0/29,0/30,0/31},{0/32,0/33,0/34,0/35},{1/0,1/1,1/2,1/3},{1/4,1/5,1/6,1/7},{1/10,1/11,1/12,1/13},{1/14,1/15,1/16,0/17},{1/18,1/19,1/20,1/21},{1/24,1/25,1/26,1/27},{1/28,1/29,1/30,1/31},{1/32,1/33,0/34,1/35}}

Hunan Moka Information Technology Co., Ltd.

A professional import and export trade company specializing in the agency sales and services of the full range of Cisco products in the United States. Our product range includes Cisco switches, Cisco routers, Cisco firewalls, Cisco wireless APs, Cisco conference terminals, Cisco optical modules, Cisco fiber optic jumpers, Cisco industrial switches, and Cisco software licenses. As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects. As a result, you can obtain the best discounts from Cisco China, typically ranging from 60% to over 90%. Due to Cisco's global sales policy, if you order Cisco licenses, with your consent and permission, we will assist you in installing and activating Cisco licenses within China. Alternatively, you can activate them in your own country, and we will transfer the licenses to you. All you need is a Cisco Smart Account. When the Cisco licenses expire, you can choose to renew them yourself or contact us.

As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects.

Huawei Router NE5000E LPUI-1T6 Integrated Line Process Unit CR5D00LRXF62 03059901
