Cisco Catalyst C9300L-Stack-Kit Overview

The Cisco Catalyst 9300 Series switches represent Cisco's flagship stackable enterprise platform meticulously crafted for security, Internet of Things (IoT), mobility, and Cloud applications, standing as the most widely deployed next-generation switching platform in the industry. The Catalyst 9300 Series switches serve as foundational components for Cisco's leading enterprise architecture, “Software-Defined Access” (SD-Access). This product embodies a top-tier stacked bandwidth solution within the industry, boasting an impressive bandwidth capacity of up to 480 Gbps, and is accompanied by an extraordinarily flexible uplink architecture.

Cisco Catalyst C9300L-Stack-Kit Switch Specification

FRU Power Supply	Yes
FRU Fans	Yes
Modular Uplinks	Yes
Stacking Bandwidth Support	480 Gbps
Cisco StackPower	Yes
Catalyst 9800 Embedded WLC	Yes (200 APs)
SD-Access Support	Yes (256 Virtual Networks)
Total 10/100/1000,Multigigabit copper or SFP Fiber	24 Multigigabit Cisco UPOE (100M, 1G, 2.5G, 5G, or 10 Gbps)
Uplink Configuration	Modular Uplinks
Default AC power supply	1100W AC
Available PoE power	560W
Total number of MAC addresses	64,000
Total number of IPv4 routes (ARP plus learned routes)	64,000
IPv6 routing entries	32,000
Multicast routing scale	16,000
QoS scale entries	18,000
ACL scale entries	18,000
Packet buffer per SKU	32 MB buffer for 24- and 48-port Gigabit Ethernet models 64 MB buffer for 24-port Multigigabit model (24UXB)
FNF entries	128,000 flow on 24- and 48-port Gigabit Ethernet models 256,000 flows on 24-port Multigigabit
DRAM	8 GB
Flash	16 GB
VLAN IDs	4094
Total Switched Virtual Interfaces (SVIs)	1000
Jumbo frames	9198 bytes
Total routed ports per Catalyst 9300 Series stack	448
Switching capacity	640 Gbps
Switching capacity with stacking	1120 Gbps
Forwarding rate	476.19 Mpps
Forwarding rate with stacking	833.33 Mpps

Cisco C9300L-Stack-Kit Scene Deployment

The Catalyst 9300 Series stands as the pioneering platform optimized for high-density Wi-Fi 6 and second-generation 802.11ac technologies, setting new benchmarks for network scalability. Prepared for future technologies, these switches feature x86 CPU architecture and expanded memory, empowering them to host containers and execute third-party applications and scripts internally within the switch.

C9300L-Stack-Kit

Cisco C9300 Series Intelligent Management

Up to 1TB of stacking bandwidth
Flexible and dense uplink offerings
Highest Multigigabit Ports
Highest 90W UPOE+ Density
100G IPsec in hardware
Secure Tunnel connectivity
Cisco ASAc Firewall enabled
Cloud management and monitoring

C9300L-Stack-Kit

The Foundation of Software-Defined access

Tailored around Cisco StackWise technology, the Catalyst 9300 Series, with support for non-stop forwarding (NSF/SSO) with stateful switchover, offers an exceptionally flexible deployment, ensuring a highly resilient stackable solution with recovery capabilities below 50 microseconds. Employing a robust and efficient power architecture integrated Cisco StackPower technology, it provides high-density Cisco Universal Power over Ethernet (Cisco UPOE) and Enhanced Power over Ethernet (PoE+) ports. Leveraging the Cisco Unified Access Data Plane (UADP) 2.0 architecture, this series not only safeguards your investments but also scales and augments throughput. The switches utilize the programmable Cisco IOS XE, a modern operating system offering advanced security features and IoT integration.

C9300L-Stack-Kit

Cisco Feature Availability

Cisco Catalyst 9300 Series switch models are designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports. Built to reimage connection, reinforce security and redefine experience

C9300L-Stack-Kit

C9300-24H-E Packing Information

The Cisco C9300-24H-E Switch is sealed in the Cisco original box. We will also pack C9300-24H-E with a second box before shipping.

Hunan Moka Information Technology Co., Ltd.

A professional import and export trade company specializing in the agency sales and services of the full range of Cisco products in the United States. Our product range includes Cisco switches, Cisco routers, Cisco firewalls, Cisco wireless APs, Cisco conference terminals, Cisco optical modules, Cisco fiber optic jumpers, Cisco industrial switches, and Cisco software licenses. As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects. As a result, you can obtain the best discounts from Cisco China, typically ranging from 60% to over 90%. Due to Cisco's global sales policy, if you order Cisco licenses, with your consent and permission, we will assist you in installing and activating Cisco licenses within China. Alternatively, you can activate them in your own country, and we will transfer the licenses to you. All you need is a Cisco Smart Account. When the Cisco licenses expire, you can choose to renew them yourself or contact us.

As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects.

Frequently Asked Questions (FAQ)

How many Cisco Catalyst 9300 Series switches C9300L-Stack-Kit can be stacked?

You can stack up to 8 switches using Cisco Stackwise-1T (C9300X), Stackwise-480 (C9300X and C9300) or Cisco Stackwise-320 (C9300L). While C9300X and C9300 models may be in the same stack, C9300L models can only stack with other C9300L models).

Can I stack Cisco Catalyst 9300 Series Switches C9300L-Stack-Kit with the Cisco Catalyst 3850 Series Switches?

These switches do not stack together. Features are packaged differently between these platforms, they use different CPU architectures, and the platforms do not have the same scaling, making stacking with them impossible.

Can I stack the Cisco Catalyst C9300L-Stack-Kit fixed and modular uplink models together?

No, the fixed uplink (C9300L) switches support StackWise-320 whereas the modular uplink (C9300X and C9300) models support StackWise-480. Catalyst 9300X only stacks support a Stackwise-1T.

What are the supported uplink modules for Cisco Catalyst 9300 Series switches C9300L-Stack-Kit?

Cisco Catalyst 9300 Series switches support the following uplink fixed and modular uplink options.

● 4x 1 Gigabit Ethernet network - fixed and modular

● 4x Multigigabit (1, 2.5, 5, or 10 Gigabit Ethernet) network – fix and modular

● 8x 10 Gigabit Ethernet SFP+ network modular

● 8x 10 Multigigabit Ethernet network modular

● 2x 25 Gigabit Ethernet SFP28 network modular

● 8x 25/10/1 Gigabit Ethernet network modular

● 2x 40 Gigabit Ethernet QSFP network - fixed and modular

● 2x 100/40 Gigabit Ethernet QSFP28 network modular

● 4x 100/40 Gigabit Ethernet QSFP28 network modular
