C9300L-24T-4X-A,Cisco Catalyst 9300L Series,3 Year License,24 Port Switch

Cisco Catalyst C9300L-24T-4X-A Overview

Catalyst 9300 series switches provide powerful intelligent network management and analysis functions by supporting Cisco DNA technology, allowing enterprises to better cope with increasingly complex network environments.

Cisco C9300L-24T-4X-A

Cisco Catalyst C9300L-24T-4X-A - Network Essentials Switch

Product Code	C9300L-24T-4X-A
Product Description	Catalyst 9300L 24p data, Network Advantage ,4x10G Uplink
Network modules options	Fixed Modules
Stack Technology	StackWise-320
Stacking bandwidt	320 Gbps
Total number of MAC addresses	32,000
Total number of IPv4 routes (ARP plus learned routes)	32,000 (24,000 direct routes and 8000 indirect routes)
IPv6 routing entries	16,000
Multicast routing scale	8,000
QoS scale entries	5,120
ACL scale entries	5,120
Packet buffer per SKU	16 MB buffer for 24 and 48 port Gigabit Ethernet models
Flexible NetFlow (FNF) entries	64,000 flow on 24- and 48-port Gigabit Ethernet models
DRAM	8 GB
Flash	16 GB
VLAN IDs	4094
Total Switched Virtual Interfaces (SVIs)	1000
Jumbo frames	9198 bytes
Switching capacity	56 Gbps - 176 Gbps
Forwarding rate	41.66 Mpps - 130.95 Mpps

Cisco C9300L-24T-4X-A Scene Deployment

Cisco® Catalyst® 9300 series switches adopt multi-level security measures in terms of security performance to ensure the security and credibility of the enterprise network. These security features make the 9300 series suitable for various enterprise network environments with high security requirements.

Cisco C9300L-24T-4X-A

Cisco C9300 Series Intelligent Management

Up to 1TB of stacking bandwidth
Flexible and dense uplink offerings
Highest Multigigabit Ports
Highest 90W UPOE+ Density
100G IPsec in hardware
Secure Tunnel connectivity
Cisco ASAc Firewall enabled
Cloud management and monitoring

Cisco C9300L-24T-4X-A

The Foundation of Software-Defined access

As part of the Cisco ecosystem, Catalyst 9300 integrates Cisco Trustworthy Solutions, a comprehensive set of security solutions that include innovative technologies at the hardware and software levels to provide comprehensive security protection.

Cisco C9300L-24T-4X-A

Cisco C9300-48T-E

Cisco C9300L-24T-4X-A Feature Availability

Cisco Catalyst 9300 Series switch models are designed for stacking switches as a single virtual switch, enabling customers to have a single management plane and control plane for up to 448 access ports. Built to reimage connection, reinforce security and redefine experience

Cisco C9300L-24T-4X-A

Packing Information

The Cisco C9300L-24T-4X-A Switch is sealed in the Cisco original box. We will also pack C9300L-24T-4X-A with a second box before shipping.

Hunan Moka Information Technology Co., Ltd.

A professional import and export trade company specializing in the agency sales and services of the full range of Cisco products in the United States. Our product range includes Cisco switches, Cisco routers, Cisco firewalls, Cisco wireless APs, Cisco conference terminals, Cisco optical modules, Cisco fiber optic jumpers, Cisco industrial switches, and Cisco software licenses. As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects. As a result, you can obtain the best discounts from Cisco China, typically ranging from 60% to over 90%. Due to Cisco's global sales policy, if you order Cisco licenses, with your consent and permission, we will assist you in installing and activating Cisco licenses within China. Alternatively, you can activate them in your own country, and we will transfer the licenses to you. All you need is a Cisco Smart Account. When the Cisco licenses expire, you can choose to renew them yourself or contact us.

As an authorized distributor of Cisco in China, we directly purchase hardware and software from Cisco China in the name of projects.

Frequently Asked Questions (FAQ)

Does the C9300L-24T-4X-A switch require a firmware upgrade?

It is recommended to regularly check for firmware updates for the C9300L-24T-4X-A switch to ensure you have the latest security patches and feature enhancements.

Are there other switches for the C9300L-24T-4X-A model?

Yes, Cisco offers a range of switches with different configurations and features. Some alternative models to consider include the C9300L-24T-4X-A for copper Ethernet connectivity or the C9300L-24T-4X-A for additional multi-gigabit ports.

C9300L-24T-4X-A switch connection problem?

First, check the physical connections and make sure they are seated correctly. Verify that the switch has power and check the LED indicators for any error messages.

How does the C9300L-24T-4X-A switch compare to similar switches from other vendors?

The C9300L-24T-4X-A switch offers comprehensive features, high performance, and scalability, making it the first choice over similar switches from other vendors.
