LST7C06HX6E0 Is Huawei S12700E Switch 6 Port 100GE QSFP28 Interface Card
Huawei S12700E Switch 6 Port 100GE QSFP28 Interface Card 03033DGH LST7C06HX6E0 Overview
LST7C06HX6E0 (03033DGH/03033DGH-001/03033DGH-002: 6-Port 100GE QSFP28 Interface Card (X6E, QSFP28)
LST7C06HX6E0 Is Huawei S12700E Switch 6 Port 100GE QSFP28 Interface Card
The LST7C06HX6E0 can be installed in:
Slots 01 to 04 in an S12700E-4 chassis.
Slots 01 to 08 in an S12700E-8 chassis.
Slots 01 to 12 in an S12700E-12 chassis.
Provides six 100GE optical ports for data transmission and switching.
Supported in V200R019C00 and later versions
Functions of the LST7C06HX6E0
Function |
Description |
Basic function |
Provides six 100GE optical ports for data transmission and switching. |
Distributed forwarding |
Performs concurrent data forwarding using a distributed data plane. |
Hot swapping |
Supported |
Basic Information Of LST7C06HX6E0
Basic Information |
|
Part Number |
03033DGH |
Model |
LST7C06HX6E0 |
Description |
6-port 100GE QSFP28 Interface Card (X6E, QSFP28) |
Level-1 category |
Interface card |
Technical Specifications |
|
Dimensions with packaging (H x W x D) [mm(in.)] |
160 mm x 510 mm x 570 mm (6.30 in. x 20.08 in. x 22.44 in.) |
Dimensions without packaging (H x W x D) [mm(in.)] |
35.1 mm x 397.2 mm x 430.4 mm (1.38 in. x 15.64 in. x 16.95 in.) |
Weight without packaging [kg(lb)] |
3.55 |
Maximum power consumption [W] |
189 |
Typical power consumption [W] |
171 |
Maximum heat dissipation [BTU/hour] |
644.89 |
Typical heat dissipation [BTU/hour] |
583.47 |
Memory |
1 GB |
